904L Chemical Filter Nozzle for Methyl Ethyl Ketone

What is Wedge Wire Screen Nozzle?

Wedge Wire screen nozzle strainer stands as the optimal replacement for traditional ABS or plastic water nozzles.

Wedge wire nozzles are a type of component used for filtration or distribution in various water treatment applications. They are made from robust Vee wires and support rods. Continuous welding technology ensured a strong and durable structure. Besides, backwashing and cleaning processes can easily remove debris. Multiple uniformly installed nozzles are widely applied in scenarios requiring filtration, such as gravity sand filters and water softeners, significantly improving the efficiency of the water distribution system. Whether filtering sediment or particulate matter, wedge wire nozzles performs well in the filtration systems.

It has a wide range of applications in water treatment applications.

The different wedge wire sizes and slot sizes can suit different class filtration.

Thier specification and quantity will vary depending on application and customer-flow requirements.

The wedge wire screen nozzle materials can use stainless steel 304, 304L, stainless steel 316, 316L, 904L,etc.

And the high-quality stainless steel 904L water strainer is commonly used in the methyl ethyl ketone unit which is thekey component of the core equipment in refining and chemical enterprises.

What's the Difference of 904L and other stainless steel water nozzles?

904L may considered as a high-performance austenitic stainless steel when compared with the general purpose austenitics such as 304 and 316. A primary feature of 904L is its excellent corrosion resistance in dilute sulphuric acid across the full range of concentrations up to 35° C. It also has useful resistance to several other inorganic acids, but its performance may be limited when halide ions are present.

904L Stainless Steel is non-magnetic in all conditions and is excellent for fabricated filters because these 904L water nozzles have good weldability and formability.

904L water filter nozzle has outstanding activation and passivation ability, excellent corrosion resistance, and good corrosion resistance in oxidizing acid such as sulfuric acid, acetic acid, formic acid, and phosphoric acid.

Common applications for SS904L filter nozzles include desalination plants, refining and chemical enterprises, ballast water management systems on oceangoing vessels, oil wells, and any filtration application with higher corrosion resistance than SS316L.
